Product Details:
Payment & Shipping Terms:
|
| Display: | 8"TFT Color LCD | Certificate: | CE |
|---|---|---|---|
| Screen: | Touch Screen | Dimension: | 334* 320* 85(mm) |
| Pixel: | 800*600 Pixels | Net Weight: | 3.5KG |
| Highlight: | Portable Ecg Monitor,Handheld Ecg Monitor |
||
Large color screen ecg 1200G cheap portable ecg machine with printer
Feature
-12 Lead ECG simultaneous acquisition,simultaneous display of3/6/12lead ECG waveform
-Build-in real-time ananlysis software,average QRS template, RS232 and USB interface
-Multiform printing modes and format:Auto/Manual,standard 12 Ch,3Ch+3R,6Ch,6Ch+1R and 60s arrhythmia report.
-Physical exemination mode (A4 Paper),R-R historgram,trend,average QRS template
-Build-in SD Card
Environment conditions
| Environment temperature | +5°C~+35°C |
| Relative humidity | ≤80% |
| Power supply | AC:100V~240V,50/60Hz DC:14.8V, 3700 mAh rechargeable lithium battery |
| Atmospheric pressure | 86kPa~106kPa |
| Environment temperature | -10°C~55°C |
| Relative humidity | ≤95% |
| Atmospheric pressure | 50kPa~106kPa |
Specifications:
| Input way | Floating and defibrilation protection |
| Lead | Standard 12 leads |
| Input impedance | ≥50MΩ |
| Frequenvy response | 0.05Hz~150Hz(-3dB,+0.4dB) |
| Time constant | >3.2s |
| CMRR | >60dB, >100dB( Adding filter) |
| EMG interference filter | 35Hz(-3dB) |
| Fuse specification | 2 pcs φ5*20mm AC time lag; T1.6A/250V(Power supply 220V) |
| Enduring polarization voltage | ±300mV |
| Measurement parameters | HR, P-R interval, P Duration, QRS Duration, T Duration, Q-T interval, Q-Tc, P A*is, QRS A*is, T A*is, R(V5) , S(V1) , R(V5)+S(V1) |
| Rhythm record | record setup according to rhythm record format and mode, automatically measuring and analysing |
| Manual record | record setup according to manual record format, manually changing leads |
| Auto record | Record setup according to auto record format and mode, automatically changing leads, measuring and analysing |
| Noise leavel | ≤13μVp-p |
| Filter | AC filter,ECG interference filter,DFT filter -Sensitivity:Auto 10,20mm/mV±2% ect |
| Measure date | HR,interval,Duration,Axis |
| Paper speed | 25,50mm/s,±%3 ect |
| Recording paper | 210/216mm(W)x20/30m(L) |
| Safety Type | Class I,Typbu xinge CF |
| Size | 338mm(L)x280MM(w)85MM(h) |
| Net Weight | 3.5Kg |
Option:
-ECG Worksation Software
-SD Card
-Portable Pack
-Trolley
-7"LCD B/W,Color,Touch
